| Technical parameter: | |
| Model | KJ-T1200-S80 |
| Furnace structure | Double-layer shell structure, equipped with a cold air system to automatically cool down the furnace shell temperature does not exceed 50 ℃ |
| chamber size | High-quality high-purity alumina polycrystalline fiber curing furnace formed by Japanese technology vacuum adsorption has good thermal insulation performance, high reflectivity and balanced temperature field. |
| Max.temperature | 1200℃ |
| Continuous working temperature | 1100℃ |
| heating rate | Recommended ≤10℃/min, the fastest heating rate is 20℃/min |
| tube size | High Purity Quartz Tube |
| Heating zone length (double hearth) |
200mm (heating area) + 150mm (heat preservation area) |
| flange | Stainless steel sealing flange, easy to disassemble, one end is a common flange, one end is a hinge flange |
| Temperature Control System | The temperature control system adopts artificial intelligence adjustment technology, with PID adjustment and self-tuning functions, and can compile 30-stage heating and cooling programs; |
| Heating element | Molybdenum alloy resistance wire |
| Temperature measuring element | K-type thermocouple, independent temperature control of two temperature zones |
| Working power | AC220V，50Hz |
| rated power | 2.2KW |
